| TECHNICAL SPECIFICATIONS : |
| Model 3 in 1 |
|
| Maximum Pressure Force : |
30 Ton |
| Returne Force : |
20 Ton |
| No of Work Stations : |
3 |
| Maximum daylight : |
450 mm |
| Minimum daylight : |
250 mm |
| Maximum Storke : |
200 mm |
| Table Size in mm : |
405x405 |
| Piston speeds (Aprox) |
|
| Approach mm/sec : |
75 |
| -Pressing mm/sec : |
4 |
| -Returne mm/sec : |
75 |
| Ejector : |
Manually Operated |
| Working Pressure : |
320 Kg/cm |
| Electric Motor : |
3 HP |
Machine are available in Manual and PLC operated models
We reserve the right to alter specifications & dimensions without notice.
|
|
|
|
